Medium Crawler Excavators
EC200E
-
44,974 - 54,388 lbs Operating weight -
154 hp Gross power -
0.36 - 1.44 yd³ Bucket capacity
Technical specifications for EC200E
| Operating weight | 44,974 - 54,388 lbs |
|---|---|
| Gross power | 154 hp |
| Engine speed at max engine torque | 2,000 rpm |
| Bucket capacity | 0.36 - 1.44 yd³ |
| Lifting capacity, along undercarriage | 16,138 lbs |
| ...at reach / height | 20 / 5 ft |
| Max. digging reach | 32′ 9″ ft in |
| Max. digging depth | 22′ 3″ ft in |
| Breakout force, SAE J1179 (Normal) | 28,101 lbf |
| Breakout force, SAE J1179 (Boost) | 29,675 lbf |
| Tear out force, SAE J1179 (Normal) | 22,706 lbf |
| Tear out force, SAE J1179 (Boost) | 24,055 lbf |
| Overall width feet inches | 9′ 10″ ft in |
| Tail swing radius | 9′ 4″ ft in |
Features & Benefits
From strong to stronger
The EC160E and EC180E not only encompasses state-of-the-art design but Volvo also recognizes that for technology to be truly innovative, top priorities need to be durability, quality and reliability for every function. This is why care has been taken to ensure every aspect of the machine is built to last while operating at the highest level of productivity.
Rops
The cab features ROPS – this reinforced steel structure ensures the operator is protected in the unlikely event of the machine rolling over, while it also meets the ISO standards for safety.
Boom and arm
The robust design includes internal plates positioned to support pressure points during the range of applications. This helps disperse the stress from high-pressure areas of the boom and arm, to ensure maximum productivity time after time, during the most demanding applications.
Lower frame
The intelligently designed X-shape lower frame enables even weight distribution increasing stability and durability - preventing damage from rock and debris.
Undercarriage
The idlers, track links, upper and bottom rollers are built to withstand all elements and terrain, to create improved long-lasting durability and support maximum uptime.
Built to last
When it comes to successful operations uptime is key and you can count on the EC200E to work harder, for longer. The balanced machine design features a robust boom and arm, strong undercarriage, protected components and heavy counterweight to comfortably take on tough work in tough environments.
Easy servicing
Complete routine servicing with speed and ease thanks to a range of features, including grouped filters accessed from the ground-level, foldable guard rails and real-time service alerts. To further improve serviceability the radiator, charged air cooler and hydraulic oil cooler are situated side-by-side on a single layer.
Work for longer
With long service intervals for oil and filter changes, the EC200E keeps working uninterrupted with fewer stops, lowering maintenance costs and minimizing disruption to your operation.
Proactive machine monitoring
ActiveCare DirectTM is a revolutionary new telematics monitoring and fleet utilization reporting service offered directly from Volvo — free for a year on applicable new machine purchases. With 24/7/365 active machine monitoring and monthly fleet reports, ActiveCare Direct allows you to spend more time making informed fleet management decisions and less time sorting through data and alarm codes.
A true all-rounder
With one machine you can take on many tasks thanks to the outstanding versatility of the EC200E, compatible with a range of attachments and suitable for a host of applications. Mix and match between a wide variety of Volvo attachments, purpose-built to work in harmony with your Volvo machine.
Buckets
Whether working with soft, medium or hard materials, Volvo buckets are the ideal tool for digging in all conditions. Volvo buckets provide maximum productivity and long life and feature original Volvo wear components.
Universal quick coupler
The Volvo Universal Quick Coupler (pin grabber type) is designed to be a perfect fit with Volvo excavators, using the latest technology to give operators precise control in locking attachments without leaving the cab. The result is a more versatile and efficient machine, saving time and money.
Thumb
The thumb can be the ideal attachment when working with rocks, debris and other irregular objects difficult to manage using only the bucket. Easy to work with thanks to the machine’s smooth and strong hydraulic system, the thumb can be easily retracted when the bucket is used for normal digging operations, yet quickly available at the flick of a switch from the cab when required.
Breaker
When working in breaking applications Volvo can offer a range of proven hydraulic breakers, designed to deliver consistent power and performance – strike after strike. Durable by design, hydraulic breakers are available with a range of work tools to suit your operation.
Building Tomorrow
Volvo is a company working today for a better tomorrow and we do that by putting customers at the heart of our organisation. It’s how we have worked for over 180 years and the EC200E continues that tradition, born out of a commitment to provide truly customer-focussed solutions.
Impressive performance
Whether digging, lifting, swinging, grading or travelling, you can count on the EC200E for the machine performance your operation demands. With power boost, the already impressive lifting and digging forces are increased further, resulting in faster cycle times and optimum productivity.
The operator’s choice
Widely regarded as an industry favourite, the Volvo cab is designed in consultation with operators based on their direct feedback. The outcome is a comfortable low-noise cab, easy-to-use controls and ergonomic layout, helping to keep operators comfortable and productive throughout their entire working shift.
Safety first
Every Volvo machine is designed with safety as a priority and the EC200E features a ROPS cab, high visibility handrails, anti-slip steps and easy access to the machine via the right-hand side. Excellent all-around visibility, side view camera and optional Volvo Smart View further help to enhance the safety of operators and those working around the machine.
At your service
More than machines, Volvo offers a comprehensive portfolio of services to complement your machine’s performance and boost your profitability. With a range of customer-focussed solutions, including fuel efficiency, productivity and uptime services, contact your local dealer to get started with Volvo Services.
-
