Volvo EC210 is a lighter machine that will be your perfect partner in agricultural applications and supporting work. But it is also popular to use for... Read more
Request Machine Information Download the EC210 brochure, with all the details and specifications. (PDF, 611.6KB)Volvo EC210 is a lighter machine that will be your perfect partner in agricultural applications and supporting work. But it is also popular to use for building, road work or utilities. With improved fuel efficiency and longer service intervals, EC210 will lower the Total Cost of Ownership while still being able to punch above its weight in performance.
Here are the key specifications for this product model. Want more details? Download the brochure or contact us.
| Operating weight | 45,149 - 52,941 lbs |
|---|---|
| Gross power | 154 hp |
| …at engine speed | 1,700 rpm |
| Bucket capacity | 0.63 - 1.88 yd³ |
| Lifting capacity, along undercarriage | 14,310 lbs |
| ...at reach / height | 20 / 10 ft |
| Max. digging reach | 32′ 10″ ft in |
| Max. digging depth | 24′ 8″ ft in |
| Breakout force, SAE J1179 (Normal) | 28,325 lbf |
| Breakout force, SAE J1179 (Boost) | 29,898 lbf |
| Tear out force, SAE J1179 (Normal) | 22,930 lbf |
| Tear out force, SAE J1179 (Boost) | 24,054 lbf |
| Overall width feet inches | 9′ 10″ ft in |
| Tail swing radius | 9′ 5″ ft in |
Based on machine configuration: EC210F L Boom 18'8" HD; Arm 5'6" HD; Shoe 24"; CWT 91,492 lb
Image illustration only. Production machines may differ in appearance and features vary between markets and models.
